HS CODE: 9016009000
LCD (white back light with black font)
Resistance-strain high-precision load cell
Cast Aluminum Base
ABS shell /Large space glass wind proof cover(ability to provide access from left, right or Top )
Stainless steel pan/Stainless steel countertop
Tare function/Counting
Unit conversion(g/mg/ct/oz/)
Overload alarm/Fault alarm
Level indicator/Adjustable leveling feet
Product Specification
Model | Capacity | Division | Repeatability | Linearity | Pan Size | Stable Time | Cal.Weight |
YK-CZ1003 | 100g | 0.001g | ±0.002g | ±0.003g | Φ90mm | ≤3s | 100g |
YK-CZ2003 | 200g | 0.001g | ±0.002g | ±0.003g | Φ90mm | ≤3s | 100g |
YK-CZ3003 | 300g | 0.001g | ±0.002g | ±0.003g | Φ90mm | ≤3s | 200g |
YK-CZ5003 | 500g | 0.001g | ±0.002g | ±0.003g | Φ90mm | ≤3s | 200g |
YK-CZ3002 | 300g | 0.01g | ±0.02g | ±0.03g | Φ125mm | ≤3s | 100g |
150*115mm | |||||||
YK-CZ6002 | 600g | 0.01g | ±0.02g | ±0.03g | Φ125mm | ≤3s | 200g |
150*115mm | |||||||
YK-CZ10002 | 1000g | 0.01g | ±0.02g | ±0.03g | Φ125mm | ≤3s | 500g |
150*115mm | |||||||
YK-C20002 | 2000g | 0.01g | ±0.02g | ±0.03g | Φ125mm | ≤3s | 500g*2 |
150*115mm | |||||||
YK-CZ30002 | 3000g | 0.01g | ±0.02g | ±0.03g | Φ125mm | ≤3s | 500g*2 |
150*115mm | |||||||
Calibration | External calibration | Draft shield size | 210*200*235mm | ||||
Power supply | 100-240V 50/60Hz Out DC 9V 500MA | Product size | 300*220*310mm | ||||
Working temps | 5-40℃ | Package size | 440*310*460mm | ||||
Interface | RS232 | N.W./G.W. | 3.2kg/4.6kg | ||||
