HS CODE: 9016001000
Internal auto calibration
LCD (White back light with black font)
Electromagnetic force high precision load cell
Cast Aluminum Base
ABS shell /Large space glass wind proof cover(Ability to provide access from left, right or Top )
Stainless steel pan/stainless steel countertop
Tare function/Counting
Unit conversion(g/ct)
Overload alarm/fault alarm
Level indicator/Adjustable leveling feet
Product Specification
Model | MECL1004 | MECL1204 | MECL2004 | MECL2204 | MECL3104 |
Max weighing(g) | 100g | 120g | 200g | 220g | 310g |
Division(g) | 0.1mg | ||||
Min weighing(g) | 10mg | ||||
Preheating time | 30min | ||||
Stable Time | ≤4s-5s | ||||
Display | LCD display | ||||
Pan Size | Φ80mm | ||||
Operation temp | 22℃±2.5℃ | ||||
Repeatability | ±0.3mg | ||||
Liner error | ±0.5mg | ||||
Draft shield size | 183×192×224mm | ||||
Dimension | 340×220×340mm | ||||
Packing size | 505×348×490mm | ||||
Calibration | Internal calibration | ||||
Cal.weights | 100g F1 | 200g F1 | |||
Interface | RS232(standard) | ||||
Power Supply | 100-240V 50/60Hz Out DC 5V 3A | ||||
N.weight | Internal: 5.9 kg | ||||
G.weight | Internal: 7.7 kg | ||||
